230550 HydroCAD
Concept HydroCAD-230550 Type II 24-hr 2-yr Rainfall=3.60"
Prepared by Lane Engineering, LLC Printed 5/26/2025
HydroCAD® 10.00-17 s/n 03788 © 2016 HydroCAD Software Solutions LLC Page 9

Pond 7P: P-2 SGW 2
Hydrograph

Inflow
3.23 cfs Outflow
Inflow Area=0.927 ac Primary
Secondary
Peak Elev=25.26'
3
Storage=4,170 cf

Flow (cfs) 2

0.95 cfs
0.95 cfs
1

0.00 cfs
0
2 4 6 8 10 12 14 16 18 20 22 24
Time (hours)
