230550 HydroCAD
            Concept HydroCAD-230550                                           Type II 24-hr  10-yr Rainfall=5.60"
            Prepared by Lane Engineering, LLC                                                   Printed  5/26/2025
            HydroCAD® 10.00-17  s/n 03788  © 2016 HydroCAD Software Solutions LLC                        Page 19

                                               Summary for Link 8L: SP-1

            Inflow Area =      2.072 ac, 48.19% Impervious,  Inflow Depth >  3.22"    for  10-yr event
            Inflow     =      3.58 cfs @  12.09 hrs,  Volume=         0.556 af
            Primary    =      3.58 cfs @  12.09 hrs,  Volume=         0.556 af,  Atten= 0%,  Lag= 0.0 min

            Primary outflow = Inflow, Time Span= 0.10-24.01 hrs, dt= 0.03 hrs


                                                       Link 8L: SP-1
                                                    Hydrograph

                                                                                                         Inflow
                  4                                                                                      Primary
                                                          3.58 cfs
                          Inflow Area=2.072 ac
                                                        3.58 cfs

                  3



               Flow  (cfs)  2







                  1




                  0
                         2      4     6     8     10    12     14    16     18    20    22     24
                                                     Time  (hours)
